65 mm 44:1 L/D TWIN SCREW EXTRUDER
65 mm Twin Screw Extruder has 44 L/D barrel design. The barrel designed as 11 pieces and resistant to high temperature. Every zone has its own heater. 65mm Twin Screw Extruder - Cooling Unit - Granulator has compact design. 65 mm Twin Screw Extruder provides high capacity production. Screw elements of twin screw extruders consist of various parts such as kneading, mixing and cutting and can be redesigned according to process. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s revolutions can be adjusted, head’s pressure and other parameters can be seen by 10' standard touch screen. The values in the formulas can be saved to the device memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use.
LABORATORY TYPE 20 MM 44:1 L/D TWIN SCREW EXTRUDER
20 mm Twin Screw Extruder has 44 L/D barrel design. The barrel is designed as eleven pieces and resistant to high temperatures. Every zones’ heater works by its own socket. Extruder has a compact design with cooling bath and granulator. Designed for testing with raw material as minimum as possible and works with the small capacity for pilot production. Allows the processing of valuable polymers by segmented screw and barrel design. The screw elements of the extruder can be redesigned for any different application by changing kneading, mixing and cutting elements. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s speeds can be adjusted,  pressure and other parameters can be seen by 10' touch screen. The values in the formulas can be saved to the  memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use. Extruder electrical panel is located at the bottom of the table. MOVABLE BARREL FEATURE In case of any jamming of the screw or for cleaning, the barrel can be easily separated from the screw. With the helping of a manual arm, the barrel can be separated from the screw together with the panel and the water system. This system provides convenience for the user in terms of cleaning and checking the screws without removing the barrel.
90 mm 48:1 L/D TWIN SCREW EXTRUDER
90 mm Twin Screw Extruder has 48 L/D barrel design. The barrel designed twelve pieces and resistant to high temperatures. Each barrel has its own heater. Extruder - Cooling Bath - Granulator has compact design and provides high capacity production. Screw elements of twin screw extruders consist of various parts such as kneading, mixing and cutting and can be redesigned according to any special request. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s revolutions can be adjusted, head’s pressure and other parameters can be seen by 10' standard touch screen. The values in the formulas can be saved to the device memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use.
50 mm 44:1 L/D TWIN SCREW EXTRUDER
50 mm Twin Screw Extruder has 44 L/D barrel design. The barrel designed as 11 pieces and resistant to high temperature. Every zone has its own heater. 50mm Twin Screw Extruder - Cooling Unit - Granulator has compact design. 50 mm Twin Screw Extruder provides high capacity production. Screw elements of twin screw extruders consist of various parts such as kneading, mixing and cutting and can be redesigned according to process. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s revolutions can be adjusted, head’s pressure and other parameters can be seen by 10' standard touch screen. The values in the formulas can be saved to the device memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use.
LABORATORY TYPE GM POYTEX MECHANIC TEXTURE MACHINE
LABORATORY TYPE POYTEX MECHANIC TEXTURE MACHINE GM POYTEX Mechanic Texture Machine is used to texture the yarn in the laboratories. The yarn is heated by oil pool for spinning and get ready for texture process. POYTEX Mechanic Texture Machine has 4 cold godets. The cycle (rpm.) can be adjusted according to yarn’s thinness, thickness or spinning speed.    Spinning angle can be changed and also actual coil diameter and empty coil diameter can be displayed by the screen. POYTEX can save your working settings with recipe page.
FRONT STITCH
LUBRICATION BEARING
AIR GUN
SHUTTLE SYSTEM
IDLER ROLL
COLD GODET SET
COLD GODET SET
COLD GODET
COLD GODET
HOT GODET SET
HOT GODET SET
HOT GODET
HOT GODET
LUBRICATION CERAMIC
SHUTTLE
MELT GEAR PUMP
TEXTURE SET
TEXTURE RESISTANCE BEARING
TEXTURE REZİSTANS YATAĞI
TEXTURE BEARING
TEXTURE BEARING
TEXTURE BODY
TEXTURE GÖVDE
NOZZLES
GM50, GM58, GM80
SPINNERET SET (SPINNERET NOT INCLUDED)
SPINNERET SET (SPINNERET NOT INCLUDED
LABORATORY TYPE GM AUTOMATIC WINDER
OTOMATIC WINDER SINGLE - DOUBLE With Automatic Coil Changer The coil winding section is the section where the endless fiber delivered by the ceramic rollers is wound onto the bobbin. Wraps the bobbins to be shipped to the desired tension and automatically changes the bobbin. The winding process is the final stage of filament spinning. The winders we produce can be 2 coils. The winding speed is maximum 4500 m / min.
LABORATORY TYPE SPINNING LINE SPINTECH IV- TRICOLOR
Laboratory type synthetic spinning unit Gülnar machine spintech line is designed for minimum capacity fiber testing in laboratory conditions. Advantages; - The dimensions were designed to fit almost all standard laboratories. - 400 grams of product with the minimum effort in a short time to provide products. - Gülnar Makina Spintech line can be designed according to the wishes of the user and can be modified afterwards. - Gülnar Makina Spintech line is a compact system designed to test new applications, new processes and new mixtures. Spintech device; - Masterbatch manufacturers; use quality, color control and blends to try. - Granule manufacturers; they use test and testing for new fibers. - Yarn manufacturers; use for development, control, color and yarn designs. - Spinoil manufacturers; use in quality and R&D stages. Gülnar Makina Spintech line is a machine with high quality standards. All data can be viewed and monitored thanks to the 12 inc touch panel, where all parameters are monitored and controlled.   If necessary, the system operating parameters can be transferred to an external disk.
LABORATORY TYPE SPINNING LINE SPINTECH III
Laboratory type synthetic spinning unit   Gülnar machine spintech line is designed for minimum capacity fiber testing in laboratory conditions.   Advantages; - The dimensions were designed to fit almost all standard laboratories. - 400 grams of product with the minimum effort in a short time to provide products. - Gülnar Makina Spintech line can be designed according to the wishes of the user and can be modified afterwards. - Gülnar Makina Spintech line is a compact system designed to test new applications, new processes and new mixtures.   Spintech device; - Masterbatch manufacturers; use quality, color control and blends to try. - Granule manufacturers; they use test and testing for new fibers. - Yarn manufacturers; use for development, control, color and yarn designs. - Spinoil manufacturers; use in quality and R&D stages.   Gülnar Makina Spintech line is a machine with high quality standards. All data can be viewed and monitored thanks to the 12 inc touch panel, where all parameters are monitored and controlled.   If necessary, the system operating parameters can be transferred to an external disk.
LABORATORY TYPE SPINNING LINE SPINTECH II
Laboratory type synthetic spinning unit Gülnar machine spintech line is designed for minimum capacity fiber testing in laboratory conditions. Advantages; - The dimensions were designed to fit almost all standard laboratories. - 400 grams of product with the minimum effort in a short time to provide products. - Gülnar Makina Spintech line can be designed according to the wishes of the user and can be modified afterwards. - Gülnar Makina Spintech line is a compact system designed to test new applications, new processes and new mixtures. Spintech device; - Masterbatch manufacturers; use quality, color control and blends to try. - Granule manufacturers; they use test and testing for new fibers. - Yarn manufacturers; use for development, control, color and yarn designs. - Spinoil manufacturers; use in quality and R&D stages. Gülnar Makina Spintech line is a machine with high quality standards. All data can be viewed and monitored thanks to the 12 inc touch panel, where all parameters are monitored and controlled. If necessary, the system operating parameters can be transferred to an external disk.
LABORATORY TYPE 250 KG GRANULATOR (PELLETIZER)
Conveyor belt or water bath systems can be used for cooling in the extrusion line. There are two options with the machine. First, standard granule cutting, second is granule size adjustable model as optional. (0.5, 1, 2, 3, mm)
LABORATORY TYPE 50 KG GRANULATOR (PELLETIZER)
Conveyor belt or water bath systems can be used for cooling in the extrusion line. There are two options with the machine. First, standard granule cutting, second is granule size adjustable model as optional. (0.5, 1, 2, 3, mm)
LABORATORY TYPE 2-6 KG GRANULATOR (PELLETIZER)
Conveyor belt or water bath systems can be used for cooling in the extrusion line. There are two options with the machine. First, standard granule cutting, second is granule size adjustable model as optional. (0.5, 1, 2, 3, mm)
LABORATORY TYPE SPINNING LINE SPINTECH I
Laboratory type synthetic spinning unit Gülnar machine spintech line is designed for minimum capacity fiber testing in laboratory conditions. Advantages; - The dimensions were designed to appropriate almost all standard laboratories. - 400 grams of product with the minimum effort in a short time to provide products. - Gülnar Machine Spintech line can be designed according to the wishes of the user and can be modified afterwards. - Gülnar Machine Spintech line is a compact system designed to test new applications, new processes and new mixtures. Spintech device; - Masterbatch manufacturers; use quality, color control and blends to try. - Granule manufacturers; they use for test and testing of new mixed fibers. - Yarn manufacturers; use for development, control, color and yarn designs. - Spinoil manufacturers; use in quality and R&D stages. Gülnar Machine  Spintech line is produced with high quality standards. All data can be viewed and monitored with 12 inc touch panel, where all parameters are monitored and controlled. If necessary, the system operating parameters can be transferred to an external disk.
LABORATORY TYPE FILTER TEST MACHINE
The Filter Test Machine provides high repeatability by advanced 25 mm extruder unit, melt pump and pressure sensors. Provides high repeatability in masterbatch, compaund and standardization works. It can measure by using filters in standard sizes (between 44 microns and 5 microns). Measurings are made according to EN-13900-5 Filter test norms. With fully automatic computer control, provides minimized user errors for the machine. Automatic result screen, data transfer with USB, data transfer to office programs, recipe saving functions. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s revolutions can be adjusted, head’s pressure and other parameters can be seen by 10' standard touch screen. The values in the formulas can be saved to the device memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use.
LABORATORY TYPE 12MM TWIN SCREW EXTRUDER
12 mm twin screw extruder has 24 L/D barrel. The barrel is designed as one piece, resistant to high temperatures. Every zones’ heaters works by its own socket. This makes possible to redesign the screw and barrel configuration for the best mixing and dispersion. 12 mm twin screw extruder is designed on a single table. Designed for allows testing with raw material as minimum as possible. Allows the processing of valuable polymers by segmented screw and barrel design. The screw elements of the extruder can be redesigned for any different application by changing kneading, mixing and cutting elements.  CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s speeds can be adjusted,  pressure and other parameters can be seen by 10' touch screen. The values in the formulas can be saved to the  memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use. Extruder electrical panel is located at the bottom of the table. GRANULATOR Conveyor belt or water bath systems can be used for cooling in the extrusion line. There are two options with the machine. First, standard granule cutting, second is granule size adjustable model as optional. (0.5, 1, 2, 3, mm)
GRAVIMETRIC FEEDER
The operating principle of GM-MIX  Gravimetric Feeder with single screw is as follow; all of the feed system is standing one of the weighing platform. When the screw system works, each unit can also be weighed and decreasing the amount of material is calculated. This material amount is compared with the goal value and given the command to the engine for the calculated suitable speed. Simultaneous control and correction process with the target value is kept in a sensitive tolerance band. Advantages GM-MIX  Gravimetric Feeder System has more important feature then the classic volumetric feed system. This feeder much more sensitive. This system provides saving of raw material to the system enrty and ensures the homogeneity of the facility to more efficient operation of the system output. Volumetric system works with %10 sensitivity but the gravimetric dosing system works by 0,2% accuracy. So it provides to save the company rate of 9,8% for each hour. It has a special software. In a special thanks to the software, the system output checks the deviations of the target value and over time realize the changes of the characteristic of flow. By this way linearity can be ensured next of the accuracy. Furthermore, during and after Refill, the system continued in a control manner to contribute to the flow linearity. The other advantages of gravimetric system are; - It provides closed-loop control system with simultaneous weight matering and feed in the amount of supervision. - Wide range limit automatically adapts differences in density of the material that may accur over time. - Material and output amount can be controlled directly. - It has high linearity. Applications Areas Loss in weight of the principle of gravimetric feeder has a wide area which sectors dosing applications commonly used. This sectors; - Plastic Industry - Food Industry - University R & D efforts in - Mining and Chemical Industry - Pharmaceutical Industry Gravimetric single screw feeder uses the following materials dosing continuous applications; - Granuler Materials - Powder Materials - Lumpy Materials - Fibrous Materials - Exfoliate Materials The Projection Thanks to its flexible design, offers suitable solutions for the different material and different capacity. Custom solutions could be found for the applications of granular, fiber or powder materials. It seems elegant with projection of single engine. Gear system running a horizontal mixer provides a linear flow to the fluency of a low coefficient of powder materials and it reduces the feeder error rate to the minimum. It provides to calculate the resolution of sensitive weighing and accurancy and linearity of supply system in a sensitive level like 0,2% rate. The control system has a friendly interface to be helpful for operators and it shows everything on the touchmatic screen.
LABORATORY TYPE 18MM TWIN SCREW EXTRUDER
18 mm Twin Screw Extruder has 44 L/D barrel design. The barrel is designed as eleven pieces and resistant to high temperatures. Every zones’ heater works by its own socket. Extruder has a compact design with cooling bath and granulator. Designed for testing with raw material as minimum as possible and works with the small capacity for pilot production. Allows the processing of valuable polymers by segmented screw and barrel design. The screw elements of the extruder can be redesigned for any different application by changing kneading, mixing and cutting elements. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s speeds can be adjusted,  pressure and other parameters can be seen by 10' touch screen. The values in the formulas can be saved to the  memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use. Extruder electrical panel is located at the bottom of the table. MOVABLE BARREL FEATURE In case of any jamming of the screw or for cleaning, the barrel can be easily separated from the screw. With the helping of a manual arm, the barrel can be separated from the screw together with the panel and the water system. This system provides convenience for the user in terms of cleaning and checking the screws without removing the barrel.
LABORATORY TYPE COUNTER ROTATE
20 mm twin screw counter rotate extruder has variable barrel desing such as 20 L/D and 22 L/D. If necesarry, the extruder can be redesigned between 22 L/D and 32 L/D. The barrel is designed as four pieces and is resistant to high temperatures. Every zones’ heaters works by its own socket. This makes it possible to redesign the screw and barrel configuration for the best mixing and dispersion. Extruder and cooling strain unit is designed on a single stand. Designed testing with as little raw material as possible.  Allows the processing of valuable polymers by its small value.   CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s revolutions can be adjusted, head’s pressure and other parameters can be seen by 10' standard touch screen. The values in the formulas can be saved to the device memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use. Extruder electrical panel is located at the bottom of the table. SPECIFICATIONS The film unit is tension controlled. The rollers are speed controlled. The rollers are (3-pcs.) stainless steel and water-cooled.  The pulling rollers' height is adjustable and made of rubber material. (Rubber hardness is 90 hrc.)  The winding system has torque controlled lining system. The films' tension can be controlled. The Chill Roll roller's height and speed can be controlled. The thickness can be adjustable between 0,2 mm and 1,5 mm. The width is between 2 cm and 5 cm.
LABORATORY TYPE 16MM TWIN SCREW EXTRUDER
16 mm twin screw extruder has variable barrel desing such as 24 L/D – 30 L/D – 35 L/D and 40 L/D. If necesarry, the extruder can be redesigned between 24 L/D and 40 L/D. The barrel is designed as seven pieces and resistant to high temperatures. This makes possible to redesign the screw and barrel configuration for the best mixing and dispersion. 16 mm twin screw extruder is designed on a single stand with cooling bath and granulator. Designed for testing with raw material as minimum as possible. Allows the processing of valuable polymers by segmented screw and barrel design. The screw elements of the extruder can be redesigned for any different application by changing kneading, mixing and cutting parts. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s speeds can be adjusted,  pressure and other parameters can be seen by 10' touch screen. The values in the formulas can be saved to the  memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use. Extruder electrical panel is located at the bottom of the table. GRANULATOR Conveyor belt or water bath systems can be used for cooling in the extrusion line. There are two options with the machine. First, standard granule cutting, second is granule size adjustable model as optional. (0.5, 1, 2, 3, mm)
LABORATORY TYPE BLOWN FILM
16 mm single screw extruder has variable barrel desing such as 24 L/D – 30 L/D – 35 L/D and 40 L/D. If necesarry, the extruder can be redesigned between 24 L/D and 40 L/D.  The barrel is designed as seven pieces and resistant to high temperatures that makes possible to redesign the screw and barrel configuration for the best mixing and dispersion.   Granulator, cast film unit, blown film unit, etc. can be applied to the Extruder. Designed testing with raw material as minimum as possible. Allows the processing of valuable polymers by changing screw and barrel design. The screw elements of the extruder can be redesigned for any different application by changing kneading, mixing and cutting elements. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s revolutions can be adjusted, head’s pressure and other parameters can be seen by 10' standard touch screen. The values in the formulas can be saved to the device memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use. Extruder electrical panel is located at the bottom of the table. BLOWN FILM UNIT SPECIFICATIONS Pulling roller system Lining and edge waste winding Height 104 cm Film width max 90 mm Film thickness min 20 microns CONTROL: Starting / Stopping Speed control Electric: with a socket from extruder main body
LABORATORY TYPE GELIMAT MIXER
HIGHT SPEED MIXSER Laboratuary mixer is disined to make mixures in 15-20 seconds without any heating with well desined special knifes and very high speed. It s very safe and quick to put the sample in or take the sample out. This system  provides high speed and low cost manufacturing TESTED COMPITABLE MATERIALS LIST HDPE, LDPE, ABS, SAN, PS, PP, TPU (60-80 hrc), PMMA, PBT, PC, SAN, POM, PC/ABS, CAP, PLA TESTED INCOMPITABLE MATERIALS LIST PVC, PA, TPE, PUR
LABORATORY TYPE DUAL STAGE PRESS
The laboratory press is used for the production of all kinds of films or stepped sheets of polymers. These are used to prepare test samples to study the mechanical, electrical, optical and chemical properties of polymers.  Upper and lower heated molds are used for the press, and cooled molds are used in the second stage. ABB electricity and 7'' touch screen are used for the control unit. All data can be saved and print. The working principle of the press is to provide smooth surface quality with gradual pressure to stepped sheet and film in desired sensitivity. Electrically heated molds provide highly accurate temperature control. Pressure ramps and duration settings can be controlled by the control panel.  CONTROL PANEL Press’ control panel is designed for easy use. Machine settings, alarm page, system settings, input-output monitoring, manual control and working graphic parameter can be seen and controlled by the standard 7" touchscreen. Pressure and temperature control Time control Mold temperature control Pressure ramp control PC supporting function Touchscreen for easy use. Graphical display Monitoring of pressure movements Errors page
LABORATORY TYPE 16MM CAST FILM UNIT
16 mm single screw extruder has variable barrel desing such as 24 L/D – 30 L/D – 35 L/D and 40 L/D. If necesarry, the extruder can be redesigned between 24 L/D and 40 L/D.  The barrel is designed as seven pieces and resistant to high temperatures that makes possible to redesign the screw and barrel configuration for the best mixing and dispersion. Granulator, cast film unit, blown film unit, etc. can be applied to the Extruder. Designed testing with raw material as minimum as possible. Allows the processing of valuable polymers by changing screw and barrel design. The screw elements of the extruder can be redesigned for any different application by changing kneading, mixing and cutting elements. CONTROL PANEL Extruder control panel is designed for easy use. The screw and feeding’s revolutions can be adjusted, head’s pressure and other parameters can be seen by 10' standard touch screen. The values in the formulas can be saved to the device memory. By the way, you can call the formulas stored in the memory by typing their number or name and get the machine ready for use. Extruder electrical panel is located at the bottom of the table. CAST FILM UNIT SPECIFICATIONS Pulling roller system Lining and edge waste winding Height 38 cm Adjustable cutting system for film width. Film thickness measuring system Film width max 90 mm Film thickness min 20 microns. CONTROL Starting / Stopping, Speed control Electric: with a socket from extruder main body
LABORATORY TYPE 25MM TWIN SCREW EXTRUDER
            25 mm twinscreew extruder with barrels 42 L/D,.Each barrel(Block) consists of seven high temperature resistant parts.Thanks to independent heater in each block that gives more ability on temperature control of blocks to have more homogenous and more dispersion final mixture.             25 mm twin screw extruders are compact machines which an extruder, water cooling and a granulator placed on a table. 25 mm extruder is providing samples by using less raw meterials and is able to produce pilot productions. To have a better mixture and a better dispersion zone heaters can be controled at different temperatures at the same time and the screew configration can be changed easily. All Plc controls and cooling unit are placed under the table.              With very friendly user control software and 10'' touch screen the control of rotational speed of feeder and screw, the set value of heaters can be adjusted very easily. In same time the Head pressure and the zone temperature values can be read from same screen. Also operator able to create unlimited new methods for different polymers, call and load them in control panel as needed.

WELCOME
        GULNAR MACHINERY founded in 2004 and produces machines which is using plastic raw materials ; Masterbatch paint machines, concentrated dye machines, front cut (granulator), laboratory mixer (gelimat), laboratory press, laboratory cylinder (kalendar), laboratory pre-cutting, pool and drying apparatus, double revision of the screw and the barrel, paint mixer (powder paint mixer). As a first time in the industry , it is continue to produce double screw extruder with all domestic production line.               Established its own company GÜLNAR PLASTİK MAKİNALARI SAN.TİC VE LTD ŞTİ in 2010. Strengthening the structure of the organization by efficient use of available resources and providing continuous improvement in product quality we are offering a flexible and innovative solutions to our customers. In addition, our production machines and systems are getting developed, expanded and diversified all the time parallel with the increasing importance for the world economy and the plastics industry. Our Vision On plastic machinery industry, using the right technology to offering valuable solutions to turnkey industrial plants with holding the highest level of customer satisfaction, exchange forwards, offering desired quality and time to be an international brand on a global level. As GULNAR MACHINERY committed the continuity of quality and quality system conformity inspection.
